Canon imagePROGRAF iPF8400 Service Manual

Chapter 1
1-2
F-1-2
[1] Upper Cover [12] Stand
[2] Ink Tank Cover [13] Maintenance Cartridge Cover
[3] Ejection Slot [14] Maintenance Cartridge
[4] Ejection Guide [15] Operation Panel
[5] Output Stacker [16] Ethernet Port
[6] Roll Holder Slot [17] USB Port
[7] Holder Stopper [18] Accessory Pocket
[8] Roll Holder [19] Media Take-up Unit Power Inlet
[9] Paper Feed Slot [20] Power Supply Connector
[10] Ejection Support [21] Carrying Handles
[11] Release Lever
[17]
[18]
[19]
[20]
[16]
[21]

Canon imagePROGRAF iPF8400 Specifications

General

Internal storage capacity	250 GB
