4 RGV16(VM) OUT Power supply(+32v)
J3002
Pin Number Signal name IN/OUT Function
1 TH IN Thermister output signal
2GND -GND
3 Vout IN Temperature/humidity sensor output signal
4 +5V OUT Power supply(+5v)
J3003
Pin Number Signal name IN/OUT Function
1 /MAKITORI_UNIT IN Media take-up paper detection sensor
2 /MAKITORI_LOCK_SENS IN Media take-up on/off sensor output signal
3 /MAKITORI_VCC_ON OUT Power supply ON signal
4 MAKITORI_VM_ON OUT Power supply(+26V)
5 /MAKITORI_ENB OUT Media take-up drive enable signal
6 PHOTO_SENS_OUT IN Media take-up paper detection sensor output signal
7 VM_26V OUT Power supply(+26V)
8 VM_26V OUT Power supply(+26V)
9 VMGND - GND
10 VMGND - GND
11 +5V OUT Power supply(+5V)
12 N.C. - N.C
13 N.C. - N.C
14 N.C. - N.C
J3150
Pin Number Signal name IN/OUT Function
1 IN 3+ IN Hole sensor input signal 3+
2 IN 3- IN Hole sensor input signal 3-
3 IN 1- IN Hole sensor input signal 1-
4 IN 2+ IN Hole sensor input signal 2+
5 IN 1+ IN Hole sensor input signal 1+
6 IN 2- IN Hole sensor input signal 2-
7 VM_GND - GND
8 +5V OUT Power supply (+5V)
9 OUT B OUT Motor output signal B
10 OUT B OUT Motor output signal B
11 OUT A OUT Motor output signal A
12 OUT A OUT Motor output signal A
13 OUT C OUT Motor output signal C
14 OUT C OUT Motor output signal C
J3201
Pin Number Signal name IN/OUT Function
A1 TANK_CLK OUT Ink tank clock signal
A2 GND - GND
A3 OUT_TANK_DAT2 IN/OUT Ink tank data signal 2
A4 TANK_+3.3V OUT Power supply(+3.3V)
A5 OUT_TANK_DAT1 IN/OUT Ink tank data signal 1
A6 OUT_TANK_DAT0 IN/OUT Ink tank data signal 0
A7 GND - GND
A8 OUT_INK_DETECT0 IN Ink detection sensor output signal 0
A9 OUT_INK_DETECT1 IN Ink detection sensor output signal 1
A10 OUT_INK_DETECT2 IN Ink detection sensor output signal 2
A11 OUT_TANK_DAT5 IN/OUT Ink tank data signal 5
A12 OUT_TANK_DAT4 IN/OUT Ink tank data signal 4
J3001
Pin Number Signal name IN/OUT Function
