Canon imagePROGRAF iPF8400 - Page 191

Chapter 6
6-11
21 GND - GND
22 H1-C-DATA-5-OD_B OUT Odd head(L) data signal 5(C)
23 GND - GND
24 H1_CLK OUT Head(L) clock signal
25 GND - GND
26 /H1_LT_B OUT Head(L) latch signal
27 GND - GND
28 H1-C-DATA-5-EV_B OUT Even head(L) data signal 5(C)
29 GND - GND
30 /H1-B-HE-3_B OUT Head(L) heat enable signal 3(B)
31 GND - GND
32 H1-C-DATA-4-EV_B OUT Even head(L) data signal 4(C)
33 GND - GND
34 H1-B-DATA-3-EV_B OUT Even head(L) data signal 3(B)
35 GND - GND
36 H1-B-DATA-2-EV_B OUT Even head(L) data signal 2(B)
37 GND - GND
38 H1-A-DATA-1-EV_B OUT Even head(L) data signal 1(A)
39 GND - GND
40 /H1-A-HE-1_B OUT Head(L) heat enable signal 1(A)
41 GND - GND
42 H1-A-DATA-0-EV_B OUT Even head(L) data signal 0(A)
43 GND - GND
44 /H1-A-HE-0_B OUT Head(L) heat enable signal 0(A)
45 GND - GND
46 H1-A-DATA-0-OD_B OUT Odd head(L) data signal 0(A)
47 GND - GND
48 VHT_ENB OUT VHT enable signal
49 HV_ENB OUT HV enable signal
50 FFC_SLANT_DET_SNS - -
J3602
Pin Number Signal name IN/OUT Function
