Canon imagePROGRAF iPF8400 Service Manual

Chapter 6
6-24
T-6-42
8VH2 -GND
9 H0-F-DATA-10-OD IN Odd head(R) data signal 10(F)
10 GND - GND
11 H0-F-DATA-11-OD IN Odd head(R) data signal 11(F)
12 GND - GND
13 H0-F-HE-11 IN Head(R) heat enable signal 11(F)
14 GND - GND
15 H0-F-DATA-11-EV IN Even head(R) data signal 11(F)
16 GND - GND
17 H0-F-DATA-10-EV IN Even head(R) data signal 10(F)
18 GND - GND
19 H0-E-HE-9 IN Head(R) heat enable signal 9(E)
20 GND - GND
21 H0-E-DATA-9-EV IN Even head(R) data signal 9(E)
22 GND - GND
23 H0-E-DATA-8-EV IN Even head(R) data signal 8(E)
24 GND - GND
25 H0-D-HE-7 IN Head(R) heat enable signal 7(D)
26 GND - GND
27 H0-D-DATA-7-EV IN Even head(R) data signal 7(D)
28 GND - GND
29 H0-D-DATA-6-EV IN Even head(R) data signal 6(D)
30 GND - GND
31 H0-D-HE-6 IN Head(R) heat enable signal 6(D)
32 GND - GND
33 H0-D-DATA-6-OD IN Odd head(R) data signal 6(D)
34 GND - GND
35 H0-D-DATA-7-OD IN Odd head(R) data signal 7(D)
36 GND - GND
37 H0-C-DATA-5-OD IN Odd head(R) data signal 5(C)
38 GND - GND
39 H0-C-HE-5 IN Head(R) heat enable signal 5(C)
40 GND - GND
41 H0-C-DATA-5-EV IN Even head(R) data signal 5(C)
42 GND - GND
43 H0-C-DATA-4-EV IN Even head(R) data signal 4(C)
44 GND - GND
45 H0-B-HE-3 IN Head(R) heat enable signal 3(B)
46 GND - GND
47 H0-B-DATA-3-EV IN Even head(R) data signal 3(B)
48 GND - GND
49 H0-B-DATA-2-EV IN Even head(R) data signal 2(B)
50 GND - GND
J203
Pin Number Signal name IN/OUT Function
1 LIFT_CAM_IN OUT Lift cam sensor output signal
2GND -GND
3 H0_CLK IN Head(R) clock signal
4GND -GND
5 H0_LT IN Head(R) latch signal
6GND -GND
7 H0-A-HE-1 IN Head(R) heat enable signal 1(A)
8VH2 -GND
9 H0-A-DATA-1-EV IN Even head(R) data signal 1(A)
10 GND - GND
11 H0-A-DATA-0-EV IN Even head(R) data signal 0(A)
12 GND - GND
13 H0-A-HE-0 IN Head(R) heat enable signal 0(A)
14 GND - GND
15 H0-A-DATA-0-OD IN Odd head(R) data signal 0(A)
16 GND - GND
J202
Pin Number Signal name IN/OUT Function
