Chapter 7
7-14
Screen 1, Screen 2 and Screen 3 are selectable with the and keys.
These screens display the associated sensor status as listed in the table below.
Display
position
Sensor name LCD display contents
1 Pump Cam Sensor 0: Sensor ON, 1: Sensor OFF
2 Valve open/closed detection sensor (R) 0: Sensor ON, 1: Sensor OFF
3 Agitation cam sensor (L) 0: Sensor ON, 1: Sensor OFF
4 Agitation cam sensor (R) 0: Sensor ON, 1: Sensor OFF
5(Not Used) -
6 Lift cam sensor 0: Sensor ON, 1: Sensor OFF
7 Feed roller HP sensor 0: Sensor ON, 1: Sensor OFF
8 Upper cover lock switch 0: Cover open, 1: Cover close
9 Carriage cover sensor 0: Cover open, 1: Cover close
10 Ink tank cover switch (R) 0: Cover open, 1: Cover close
11 Ink tank cover switch (L) 0: Cover open, 1: Cover close
12 (Not Used) -
13 (Not Used) -
14 (Not Used) -
15 (Not Used) -
16 (Not Used) -
17 (Not Used) -
18 (Not Used) -
19 (Not Used) -
20 (Not Used) -
21 (Not Used) -
22 Carriage HP sensor 0: Sensor ON, 1: Sensor OFF
23 Pressure release switch 0: Realeased, 1:Pressured
24 Media sensor 0: No media, 1: Media loaded
25 (Not Used) -
26 (Not Used) -
27 (Not Used) -
28 Media take-up unit detection 0: Undetected, 1: Detected
29 Media take-up sensor input signal 0: LO, 1: HI
30 Valve open/closed detection sensor (L) 0: Sensor ON, 1: Sensor OFF
31 (Not Used) -
32 (Not Used) -
33 (Not Used) -
34 (Not Used) -
35 (Not Used) -
36 (Not Used) -
37 (Not Used) -
38 (Not Used) -
39 (Not Used) -
40 (Not Used) -
41 (Not Used) -
42 (Not Used) -
43 (Not Used) -
44 (Not Used) -
45 Flexible cable connection detection
(J3501, J3502, J3601, J3602)
0: Connection, 1: Disconnection
46 (Not Used) -
47 (Not Used) -
48 (Not Used) -
To Next Page
