Canon imagePROGRAF iPF8400 Service Manual

Chapter 7
7-22
5) EXCHANGE: Counters related to parts replacement
6) DETAIL-CNT: Other counters
7) INK-USE1: Counters related to ink consumption
Display Description Unit
MTC EXC. Maintenance cartridge replacement count Times
HEAD L EXC. Printhead L replacement count Times
HEAD R EXC. Printhead R replacement count Times
BOARD EXC.(M/B) Main controller PCB replacement count Times
Wia-1 EXC. Wia-1 (waste ink box unit) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS Wia-1])
Times
Wia-3 EXC. Wia-3 (platen ink box unit) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS Wia-3])
Times
Wia-4 EXC. Wia-4 (platen ink box unit) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS Wia-4])
Times
Wia-5 EXC. Wia-5 (platen ink box unit) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS Wia-5])
Times
Wia-6 EXC. Wia-6 (suction fan unit) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS Wia-6])
Times
CR-1 EXC. CR-1 (carriage unit bushing) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS CR-1])
Times
CR-2 EXC. CR-2 (linear encoder sensor/linear scale/shaft cleaner) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS CR-2])
Times
CR-3 EXC. CR-3 (carriage height changing cam) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS CR-3])
Times
CR-4 EXC. CR-4 (ink tube unit/flexible cable unit) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS CR-4])
Times
CR-5 EXC. CR-5 (multi sensor) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS CR-5])
Times
PG-1 EXC. PG-1 (purge unit) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS PG-1])
Times
HMa-1 EXC. HMa-1 (head management sensor) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS HMa-1])
Times
MT-1 EXC. MT-1 (carriage motor) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS MT-1])
Times
PL-1 EXC. PL-1 (feed motor) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS PL-1])
Times
Mi-1 EXC. Mi-1 (mist fan) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS Mi-1])
Times
MS-1 EXC. MS-1 (multi sensor) replacement count
(Count of executing [INITIALIZE] > [PARTS COUNTER] > [PARTS MS-1])
Times
Display Description Unit
MOVE PRINTER Number of times "Prep.MovePrinter" on Main menu is executed. Times
N-INKCHK(XX) XX: Ink color
Count of turning off the ink remaining level detection for each color
Times
MEDIACONFIG-CNT Count of media registered by media editor Times
Display Description Unit
INK-USE1(XX) XX: Ink color
Cumulative consumption amount of generic ink
ml
INK-USE1(TTL) Total amount of cumulative consumption of generic ink ml
LINK-USE1(XX) XX: Ink color
Cumulative consumption amount of generic large ink
ml
LINK-USE1(TTL) Total amount of cumulative consumption of generic large ink ml
SINK-USE1(XX) XX: Ink color
Cumulative consumption amount of generic small ink
ml
SINK-USE1(TTL) Total amount of cumulative consumption of generic small ink ml
N-INK-USE1(XX) XX: Ink color
Cumulative consumption amount of refilled ink
ml
N-INK-USE1(TTL) Total amount of cumulative consumption of refilled ink ml
