Canon imagePROGRAF iPF8400 Service Manual

Chapter 7
7-24
13) MEDIASIZE2 ROLL: Counters related to roll media printing
14) MEDIASIZE1 CUT: Counters related to cut sheet printing
15) MEDIASIZE2 CUT: Counters related to cut sheet printing
16) HEAD DOT CNT.1: Counter related to dot count
17) HEAD DOT CNT.2: Counter related to dot count
Display Description Unit
D-SQ 44-60 Cumulative print area of paper equal to or larger than 44 inches but less than 60 inches (data size) m2/Sq.f
D-SQ 36-44 Cumulative print area of paper equal to or larger than 36 inches but less than 44 inches (data size) m2/Sq.f
D-SQ 24-36 Cumulative print area of paper equal to or larger than 24 inches but less than 36 inches (data size) m2/Sq.f
D-SQ 17-24 Cumulative print area of paper equal to or larger than 17 inches but less than 24 inches (data size) m2/Sq.f
D-SQ -17 Cumulative print area of paper less than 17 inches (data size) m2/Sq.f
D-CNT 44-60 Cumulative number of sheets of A4-equivalent paper equal to or larger than 44 inches but less than 60 inches
(data size)
sheets
D-CNT 36-44 Cumulative number of sheets of A4-equivalent paper equal to or larger than 36 inches but less than 44 inches
(data size)
sheets
D-CNT 24-36 Cumulative number of sheets of A4-equivalent paper equal to or larger than 24 inches but less than 36 inches
(data size)
sheets
D-CNT 17-24 Cumulative number of sheets of A4-equivalent paper equal to or larger than 17 inches but less than 24 inches
(data size)
sheets
D-CNT -17 Cumulative number of sheets of A4-equivalent paper less than 17 inches (data size) sheets
Display Description Unit
P-SQ 44-60 Cumulative print area of paper equal to or larger than 44 inches but less than 60 inches (physical size) m2/Sq.f
P-SQ 36-44 Cumulative print area of paper equal to or larger than 36 inches but less than 44 inches (physical size) m2/Sq.f
P-SQ 24-36 Cumulative print area of paper equal to or larger than 24 inches but less than 36 inches (physical size) m2/Sq.f
P-SQ 17-24 Cumulative print area of paper equal to or larger than 17 inches but less than 24 inches (physical size) m2/Sq.f
P-SQ -17 Cumulative print area of paper less than 17 inches (physical size) m2/Sq.f
P-CNT 44-60 Cumulative number of sheets of A4-equivalent paper equal to or larger than 44 inches but less than 60 inches
(physical size)
sheets
P-CNT 36-44 Cumulative number of sheets of A4-equivalent paper equal to or larger than 36 inches but less than 44 inches
(physical size)
sheets
P-CNT 24-36 Cumulative number of sheets of A4-equivalent paper equal to or larger than 24 inches but less than 36 inches
(physical size)
sheets
P-CNT 17-24 Cumulative number of sheets of A4-equivalent paper equal to or larger than 17 inches but less than 24 inches
(physical size)
sheets
P-CNT -17 Cumulative number of sheets of A4-equivalent paper less than 17 inches (physical size) sheets
Display Description Unit
D-SQ 44-60 Cumulative print area of paper equal to or larger than 44 inches but less than 60 inches (data size) m2/Sq.f
D-SQ 36-44 Cumulative print area of paper equal to or larger than 36 inches but less than 44 inches (data size) m2/Sq.f
D-SQ 24-36 Cumulative print area of paper equal to or larger than 24 inches but less than 36 inches (data size) m2/Sq.f
D-SQ 17-24 Cumulative print area of paper equal to or larger than 17 inches but less than 24 inches (data size) m2/Sq.f
D-SQ -17 Cumulative print area of paper less than 17 inches (data size) m2/Sq.f
D-CNT 44-60 Cumulative number of sheets of A4-equivalent paper equal to or larger than 44 inches but less than 60 inches
(data size)
sheets
D-CNT 36-44 Cumulative number of sheets of A4-equivalent paper equal to or larger than 36 inches but less than 44 inches
(data size)
sheets
D-CNT 24-36 Cumulative number of sheets of A4-equivalent paper equal to or larger than 24 inches but less than 36 inches
(data size)
sheets
D-CNT 17-24 Cumulative number of sheets of A4-equivalent paper equal to or larger than 17 inches but less than 24 inches
(data size)
sheets
D-CNT -17 Cumulative number of sheets of A4-equivalent paper less than 17 inches (data size) sheets
Display Description Unit
XX XX: Ink color
Dot counts of each colors of the currently installed printhead
(x 1,000,000) dots
TTL Total dot counts of each colors of the currently installed printhead (x 1,000,000) dots
Display Description Unit
XX XX: Ink color
Cumulative dot counts of each colors
(x 1,000,000) dots
TTL Total cumulative dot counts of each colors (x 1,000,000) dots
