CHAPTER 5 PICK-UP/FEEDING SYSTEM
COPYRIGHT © 1999 CANON INC. CANON NP6512/6612/7120/7130/7130F REV.0 AUG. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
5-31
4) Remove the two bushings [7].
Figure 5-235
Figure 5-236
5) While shifting the delivery lower guide
[8] toward the rear, detach the delivery
roller [9].
[7]
[8]
[9]
