CHAPTER 7 EXTERNALS/AUXILIARY MECHANISMS
COPYRIGHT © 1999 CANON INC. CANON NP6512/6612/7120/7130/7130F REV.0 AUG. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON) 7-8
Figure 7-301 (Copyboard type)
[1]
[2]
[3]
[7]
[6]
[5]
[4]
[1] Copyboard cover
[2] Top cover
[3] Control panel
[4] Front lower cover
[5] Cassette
[6] Front upper cover
[7] Left cover
A. External Covers
For instructions on how to remove the
ADF, see Chapter 8.
