Canon NP6512 - Timing Chart for the Image Formation System

CHAPTER 4 IMAGE FORMATION SYSTEM
COPYRIGHT © 1999 CANON INC. CANON NP6512/6612/7120/7130/7130F REV.0 AUG. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
4-3
Figure 4-102








Copy Start key
ON
STBY INTR SCFW
forward
SCFWSCRV
Reverse
3200V
LSTR
STBY
Main motor (M1)
Scanning lamp (LA1)
Pre-exposure lamp
Transfer bias
Transfer cleaning bias
Transfer reference
bias (ATVC)
Static eliminator bias
Pre-registration roller
paper sensor (Q751)
Primary bias
Developing AC bias
Developing DC bias
Scanner
SCRV
-500V
0.6sec.(approx.)
B. Timing Chart for the Image Formation System
Basic Sequence of Operations (Direct, 2 copies, continuous)
