Canon NP6512 - Cross Section

CHAPTER 1 GENERAL DESCRIPTION
COPYRIGHT © 1999 CANON INC. CANON NP6512/6612/7120/7130/7130F REV.0 AUG. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON) 1-11
[1] No. 3 mirror
[2] No. 2 mirror
[3] No. 1 mirror
[4] Scanning lamp
[5] Heat exhaust fan
[6] Copyboard glass
[7] Drum Unit
[8] Pre-exposure lamp
[9] Side blanking lamp
[10] Lens
[11] No. 6 mirror
[12] Primary charging roller
cleaning pad
[13] No. 4 mirror
[14] No. 5 mirror
[15] Multifeeder tray
[16] Vertical path roller
[17] Multifeeder pickup roller
[18] Cassette pickup roller
[19] Developing assembly
[20] Registration roller
[21] Developing cylinder
[22] Photosensitive drum
[23] Transfer roller
[24] Static eliminator
[25] Primary charging roller
[26] Feed belt
[27] Cassette
[28] Fixing upper unit
[29] Fixing lower roller
[30] Cleaning roller
[31] Delivery roller
[32] Copy tray
[1] [2] [3] [4] [5] [6] [7] [8] [9] [10] [12][11] [13] [14] [15]
[16][17][18][19][20][21][22][23][24][25][26][27][28][29][30][31][32]
B. Cross Section
1. Body
Figure 1-306
