CHAPTER 1 GENERAL DESCRIPTION
COPYRIGHT © 1999 CANON INC. CANON NP6512/6612/7120/7130/7130F REV.0 AUG. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON) 1-19
VI. IMAGE FORMATION
A. Outline
The construction of the machine is as follows:
Figure 1-601
Scanning lamp
Copyboard glass
Fixed focal point lens
Side blanking lamp
(front, rear)
Developing
blade
Developing
cylinder
Photo-
sensitive drum
Primary charging roller
Cleaning blade
Transfer charging roller
Static eliminator
Pre-exposure
lamp
Fixing assembly
