CHAPTER 3 EXPOSURE SYSTEM
COPYRIGHT © 1999 CANON INC. CANON NP6512/6612/7120/7130/7130F REV.0 AUG. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
3-17
Figure 3-306
Wind 1.5 times.
(black cable)
Wind 7.5 times.
(silver-colored cable)
2. Outline of the Scanner Drive Cable
