Load a media roll (position 2)
Introduction
You can load your media in the front of the drawer on position 1, or in the back of the drawer on
position 2. Load the media for position 1 and 2 similarly for both drawers.
NOTE
• To spare your back, it is advised to load an A0 or E-size media roll on position 1 and an A2 or
C-size media roll on position 2.
• To improve productivity, it is advised to load the most used media in the upper drawer.
CAUTION
• Loading heavy media, 10kg or more, on position 2, 3, or 4 has to be done by two people or
with the help of external lifting tools.
• Watch your fingers when you handle the media roll.
• If you want to load an A0 media roll on position 2,make sure to bend your knees, as indicated
below, to spare your back.
Procedure
1.
Pull firmly to open the media drawer.
2.
Place the new media roll on the roll loading station.
3.
Pull (1) the handle of the roll holder locking mechanism toward you.
Slide (2) the roll holder into the right side of the core of the new media roll.
Load a media roll (position 2)
240
Chapter 6 - Maintain the Printing System
