Canon Oce PlotWave 550 - Clearing Tape Jams in Reinforcement Unit

Clear a tape jam in the reinforcement unit
Introduction
When a tape jam occurs in the reinforcement unit, an error message appears on the user panel.
Procedure
1.
Open the front door of the reinforcement unit
[36] Opening the front door of the reinforcement unit
2.
Turn the two guide plates away from the pin roller and lock the two guide plates into their open
position.
[37] Open the guide plates
Clear a tape jam in the reinforcement unit
