5 Brake Pedal . . . . . . . . . . . . Brake pedal is used to stop machine. When brake pedal
is depressed, drive lever returns to neutral position and
brake is engaged.
6 Parking Brake Lock Lever
.
Parking brake lock lever is used when parking machine
securely. Pulling parking lock lever while brake pedal is
depressed locks brake pedal.
7 Auxiliary Transmission . . . Auxiliary transmission shift lever is used to shift auxiliary
transmission to change the speed of the machine.
8 2WD/AWD Shift Lever . . . . 2WD/AWD shift lever is used to switch between 2WD
(rear-wheel drive) and AWD (all-wheel drive) modes.
9 Differential Lock Lever . . . Differential lock lever is used to lock differential when rear
wheels slip. Tilting differential lock lever to [ON] position
locks differential.
10 Cutting Height Adjust . . . . Cutting height adjust lever is used to adjust the cutting
height.
11 Cutting Rotary Clutch . . . . Cutting rotary clutch lever is used to start or stop rotating
cutting rotary.
12 Cutting Height Memory . . Cutting height memory lever is used to set the desired
minimum cutting height.
13 Tilt Lever . . . . . . . . . . . . . . . Tilt lever is used to adjust the angle of steering wheel.
14 Head Lamp Switch . . . . . . . Head lamp switch is used to turn on or off head lamps.
When head lamps are on, switch is also illuminated.
15 Tail Lamp Switch . . . . . . . . Tail lamp switch is used to turn on or off tail lamp. When
tail lamp is on, switch is also illuminated.
16 Fuel Gauge . . . . . . . . . . . . . Fuel gauge indicates the amount of fuel in fuel tank.
Shift Lever
Lever
Lever
Lever
(CMX222 only)
