CanyCom CMX222 - Adjusting Seat Suspension (CM223 Only)

Operation
-20-
4
Adjusting Seat Suspension (CM223 Only)
1. Lift seat up
2. Loosen lock nut.
3. Turn adjust nut toward A direction to harden
suspension.
4. Turn adjust nut toward B direction to soften
suspension.
5. Tighten lock nut.
6. Put seat back.
5323M-0401-020E
Lock Nut
Adjust Nut
A
B
5323M-0401-010E
Seat
