-47-
Maintenance 5
Item Part No. Schedule Qty.
Cutting System
Blade Set (Pink) Z3214212010 Replace if defective. 1
Blade Set (Silver) Z3214206010 Replace if defective. 1
Blade Set (Black)
Z3104205010 Replace if defective. 1
Z3104205050 Replace if defective. 5
Blade Set (Red)
Z3096201010 Replace if defective. 1
Z3096201030 Replace if defective. 3
Z3096201050 Replace if defective. 5
Z3096201100 Replace if defective. 10
Rubber Plate (Front Skirt, Center)*1 53212116000 Replace if defective. 1
Rubber Plate (Front Skirt, Sides)*1 53212121000 Replace if defective. 2
Rubber Plate (Front Axle.-Blade Shield) *1 53212112000 Replace if defective. 1
Rubber Plate (Front Axle, RearRight) *1 53212118000 Replace if defective. 1
Rubber Plate (Front Tire, Inside)*1 53212142000 Replace if defective. 2
Rubber Plate (Front Skirt, Center)*2 53232124000 Replace if defective. 1
Rubber Plate (Front Skirt, Sides)*2 53232128000 Replace if defective. 2
Rubber Plate (Front axle, -Blade Shield) *2 53232126000 Replace if defective. 1
Rubber Plate (Front axle, Rear Right ) *2 53212118000 Replace if defective. 1
Rubber Plate (Front Tire, Behind ) *2 53212132000 Replace if defective. 2
Rubber Plate ( Front Tire, Inside ) *2 53062121000 Replace if defective. 2
Rubber Plate (Blade Shield, Rear) 53214125000 Replace if defective. 1
Rubber Plate (Blade Shield, Rear Left) 53214124000 Replace if defective. 1
V-Belt (Cutting Rotary)
08521600037 Replace if defective. 2
Brake Lining (Cutting Rotary)
73054005000 Replace if defective. 2
Wire (Cutting Rotary Clutch)
53132431000 Replace if defective. 1
Wire (Cutting Height Adjuster)
53214013000 Replace if defective. 1
Cutting Height Adjuster Lock
53214009000 Replace if defective. 1
Cutting Blade Stay 53214204000 Replace if defective. 1
Blade Replace Tool*3 53139004000
Electrical System
Battery (38B19R) 37053901000 Replace if defective. 1
Fuse, 30A (Green, Main) 09801003002 Replace if defective. 1
Fuse 10A (Red, Lights) 09801001002 Replace if defective. 1
Light Bulb (Head Lamp) 09808121509 Replace if defective. 2
Light Bulb (Tail Lamp) 09808120318 Replace if defective. 1
Chassis
Wire (Seat Height Adjuster)*1 53213533000 Replace if defective. 1
Height Adjuster Lock *1 53213525100 Replace if defective. 1
*1 CMX222
*2 CM223
*3 Can not use for Blade Set "Silver" or "Pink"
