1. Remove upper and lower rear covers.
2. Adjust the length B of spring with adjust nut
so that it is approximately 106mm when
clutch lever is in [OFF] position.
3. Adjust the play C with turn buckle so that it is
between 3mm and 5mm when clutch lever is
in [OFF] position.
4. Install upper and lower rear covers back in
place.
5. Check if cutting blade stops within 5 seconds.
If it does not, consult with your CANYCOM
representative.
