55
ENGLISH
ir33 +030220441 - rel. 2.0 - 01.05.2006
HF1 and HF2 access a submenu where, by pressing the * and * buttons, the year, month, day, hour,
minutes and duration of the last HF alarm activated can be scrolled.
E.g: ‘y03’ -> ‘M08’ -> ‘d29’ -> ‘h19’ -> ‘m45’ -> ‘t98’
indicates that the last alarm HA was activated on 29 July 2003 at 19:45 and lasted 98 hours.
Default HF/1/2= 0
Htd: HACCP alarm delay
Delay time in minutes that, added to the time Ad, determines the time interval after which the HA error
is activated. If set to 0, HACCP monitoring (both HA and HF) is disabled.
Any alarms already saved will still be stored, even when Htd=0.
Default: Htd=0=> HACCP monitoring disabled.
7.9 RTC and timed defrost management parameters
No. Code Parameter MSYF UOM Type Min Max Def.
117 td1 Defrost time band 1 -SYF - C - - -
d__ Day **** Days * 0 11 0
h__ Hours **** Hours * 0 23 0
n__ Minutes **** Min. * 0 59 0
118 td2 Defrost time band 2 -SYF - C - - -
119 td3 Defrost time band 3 -SYF - C - - -
120 td4 Defrost time band 4 -SYF - C - - -
121 td5 Defrost time band 5 -SYF - C - - -
122 td6 Defrost time band 6 -SYF - C - - -
123 td7 Defrost time band 7 -SYF - C - - -
124 td8 Defrost time band 8 -SYF - C - - -
125 ton Light/aux on time band -SYF - C - - -
d__ Day **** Days * 0 11 0
h__ Hours **** Hours * 0 23 0
n__ Minutes **** Min. * 0 59 0
126 toF Light/aux off time band -SYF - C - - -
d__ Day **** Days * 0 11 0
h__ Hours **** Hours * 0 23 0
n__ Minutes **** Min. * 0 59 0
127 tc RTC date/time setting MSYF - C - - -
y__ Year **** Years 0 0 99 00
M__ Month **** Month 1 1 12 1
d__ Day of the month **** Days 1 1 31 1
u__ Day of the week **** Days 6 1 7 6
h__ Hours **** Hours 0 0 23 0
n__ Minutes **** Min. 0 0 59 0
Tab. 7.t
td1...td8: Defrost time band 1 to 8
These parameters can be used to set up to 8 defrost events linked to the system clock. To display and
set or modify one of the events, access one of the parameters between td1 and td8, and then press SET.
This enters a submenu in which the up or down button can be used to display and set the day, hour and
minutes of the defrost event.
In the following example: day 8 (from Monday to Friday), hours 23, minutes 57. To modify the day,
hour or minutes of the event, access the desired parameter by pressing the up or down button and then
press SET to modify the value: the letter identifying the parameter disappears, and, at this point, the
value can be increased or decreased using SorT.
The parameter d__ sets the day of the event, as follows:
‘d__’=0 => event disabled
‘d__’=1 to 7 => Monday to Sunday
‘d__’=8 => from Monday to Friday
‘d__’=9 => from Monday to Saturday
‘d__’=10 => Saturday and Sunday
‘d__’=11 => every day
Setting ‘h__’ (0 to 23), ‘m__’ (0 to 59) sets the hour and minutes of the event.
Default: ‘d__’=0, ‘h__’=0, ‘m__’=0 => Event disabled
Pressing SET temporarily saves the changes to the modifi ed parameter and returns to the submenu
for setting the event. The display or modifi cation of the parameters corresponding to the event can be
continued, or return to the list of RTC parameters by pressing prg.
ton and tof - light/aux on/off time bands: These parameters are used to set the on/off of the light or
the aux, based on the system clock (to select aux or light, see parameter H8); in addition, the set point
can be modifi ed based on the system clock (for the activation and the description of the function, see
parameter H9). To display, set or modify one of the two events, access one of the two parameters, ton or
toF, and then press SET. Use the ton parameter to set on time, and the toF parameter to set the off time.
Press SET to enter a submenu where the SorT button can be used to display and set the day, hour
and minutes of the defrost ON or OFF event.
For example, to set ON from Monday to Saturday at 8.30, and OFF from Monday to Saturday at 19.30:
The parameter d__ sets the day of the event, as follows:
‘d__’=0 => event disabled
‘d__’=1 to 7 => Monday to Sunday
‘d__’=8 => from Monday to Friday
