ir33 +030220441 - rel. 2.0 - 01.05.2006
8.2 Table of alarms and signals: functions enabled/disabled
The following table highlights the functions that are enabled and disabled in the various alarm situations.
Code PD valve Compressor Defrost Evap. fans Cond. fans Continuous cycle
rE Duty setting (c4) Duty setting (c4) unchanged unchanged unchanged unchanged
E0 Duty setting (c4) Duty setting (c4) unchanged unchanged unchanged unchanged
E1 unchanged unchanged unchanged unchanged unchanged unchanged
E2 unchanged unchanged unchanged unchanged unchanged unchanged
E3 unchanged unchanged unchanged unchanged unchanged unchanged
E4 unchanged unchanged unchanged unchanged unchanged unchanged
‘___’ unchanged unchanged unchanged unchanged unchanged unchanged
LO unchanged unchanged unchanged unchanged unchanged unchanged
HI unchanged unchanged unchanged unchanged unchanged unchanged
AFr off off unchanged unchanged unchanged unchanged
IA Duty Setting (A6) Duty setting (A6) unchanged unchanged unchanged unchanged
dA Duty setting (A6) if A7<>0 Duty setting (A6) if A7<>0 unchanged unchanged unchanged unchanged
dEF unchanged unchanged unchanged unchanged unchanged unchanged
Ed1 unchanged unchanged unchanged unchanged unchanged unchanged
Ed2 unchanged unchanged unchanged unchanged unchanged unchanged
Pd unchanged unchanged unchanged unchanged unchanged unchanged
LP off off unchanged unchanged unchanged unchanged
Ats unchanged unchanged unchanged unchanged unchanged unchanged
cht unchanged unchanged unchanged unchanged unchanged unchanged
CHt off off unchanged unchanged unchanged unchanged
dor unchanged unchanged unchanged unchanged unchanged unchanged
Etc unchanged unchanged unchanged unchanged unchanged unchanged
EE off off unchanged off off unchanged
EF off off not performed off off not performed
HA unchanged unchanged unchanged unchanged unchanged unchanged
HF unchanged unchanged unchanged unchanged unchanged unchanged
n1-n6 unchanged unchanged unchanged unchanged unchanged unchanged
dnL unchanged unchanged unchanged unchanged unchanged unchanged
d1 - d6 unchanged unchanged unchanged unchanged unchanged unchanged
Tab. 8.b
Code
AUX dead zone
AUX light anti-sweat AUX auxiliary anti sweat AUX second step
rE off off off Duty setting (C4)
E0 off off off Duty setting (C4)
E1 unchanged unchanged unchanged unchanged
E2 unchanged unchanged unchanged unchanged
E3 unchanged unchanged unchanged unchanged
E4 unchanged unchanged unchanged unchanged
‘___’ unchanged unchanged unchanged unchanged
LO unchanged unchanged unchanged unchanged
HI unchanged off off unchanged
AFr unchanged unchanged unchanged off
IA off off off Duty setting (A6)
dA off if A7<>0 off if A7<>0 off if A7<>0 Duty setting (A6) if A7<>0
dEF unchanged unchanged unchanged unchanged
Ed1 unchanged unchanged unchanged unchanged
Ed2 unchanged unchanged unchanged unchanged
Pd unchanged unchanged unchanged unchanged
LP unchanged unchanged unchanged off
Ats unchanged unchanged unchanged unchanged
cht unchanged unchanged unchanged unchanged
CHt off off unchanged off
dor unchanged unchanged unchanged unchanged
unchanged unchanged unchanged unchanged
EE off off off off
EF off off off off
HA unchanged unchanged unchanged unchanged
HF unchanged unchanged unchanged unchanged
n1 - n6 unchanged unchanged unchanged unchanged
dnL unchanged unchanged unchanged unchanged
d1 - d6 unchanged unchanged unchanged unchanged
tab. 8.c
