CASE CONSTRUCTION 1107EX - Hydraulic oil filter - Replace

7-MAINTENANCE
Every500hours
Hydraulicoillter-Replace
1.Thehydraulicoillterisanemeshmediumpressure
lter.Thisissuctionlterequippedwithdifferential
pressureindicatorwhichshowsindicationofclogging
oflteroncontrolpanel.lterisprovidedwithamag-
neticcorewhichattractsalltheferrousparticlesformed
byfrictionandwearforces.Filterisusedinchargecir-
cuittoremovethecontaminationfromhydraulicoil.
(A)-Filtercover
(B)-Filterelement
(C)-Sealingring
(D)-Pressuresensor
(E)Filtertopcover.
PTIL14COM0057AA1
2.T ochangethelterelement:-
1.Loosentheltercoverfromlterassemblyandre-
moveittogetherwiththelterelement.
2.ChecktheO-rings,sealandreplaceifnecessary.
3.Installnewlterelementandretthecover.
NOTE:Useonlyspeciedandgenuinehydraulicoillter.
