CASE CONSTRUCTION 1107EX - Vibratory roller - Change fluid

7-MAINTENANCE
Vibratoryroller-Changeuid
1.Keepthemachineonleveledground.Turnthedrum
untiloilplugisverticallypositionedbelowthedrumaxle
center.Cleanthesurroundingsoftheplug.Unscrewoil
plug.Oilwillrunout.Draintheoilcompletely.Rotate
thedrumtoplaceoilllingportattopandllinwiththe
freshoil.
(A)-Oilexciter
NOTICE:Donotoperatethemachineinvibrationmode
whentheballastingisdone.Ifthevibrationmodeisturned
ON,theAntiVibrationMounting(AVM)padswillgetdam-
agedimmediately.
