CASE CONSTRUCTION 1107EX - Fuse and relay box - General specification

9-SPECIFICATIONS
Fuseandrelaybox-Generalspecication
1.Thefuseandrelaybox(1)islocatedbelowtheopera-
torplatform.thelocationissameforthemachinewith
cabalso.
2.Removetheboltsontheleft-handsideoftheequip-
menttogainaccesstotherelayandfusebox.
PTIL14COM0117AB1
3.Thefusedesignationsareasshowintheimage.
PTIL15COM2187AA2
Fuse
Description
10AHazard
15A
Highbeam
15ALowbeam
15A
Sideworkinglight
10A
Chargersocket
10A
Stoplamp
10AHorn
10A
FIPSolenoid
10A
Parking/Position
15A
Frontworklight
15A
Lowfrequency
10A
Cluster
10A
Highspeed
15A
Rearworkinglight
15A
Highfrequency
10AHourmeter
10AReversebuzzer
15A
Parkinglamp
10AHazard
9-10
