CASE CONSTRUCTION 1107EX - Overhead controls; Heating, Ventilation, Air-Conditioning (HVAC) controls

3-CONTROLSANDINSTRUMENTS
Overheadcontrols
Heating,Ventilation,Air-Conditioning(HVAC)controls
WARNING
Explosionhazard!
Air-conditioningrefrigerantboilsat-26°C(-15°F)!
-NEVERexposeanypartoftheair-conditioningsystemtoadirectameorexcessiveheat.
-NEVERdisconnectordisassembleanypartoftheair-conditioningsystem.
Dischargingrefrigerantgasintotheatmosphereisillegalinmanycountries.
Failuretocomplycouldresultindeathorseriousinjury.
W0340B
WARNING
Escapingrefrigerantmaycausefrostbite!
Ifyougetrefrigerantonyourskin:
-Warmtheareawithyourhandorlukewarmwater,32-38°C(90-100°F).
-Coverthearealooselywithabandagetoprotecttheareaandthepreventinfection.
-Seekmedicalassistanceimmediately.
Failuretocomplycouldresultindeathorseriousinjury.
W0341A
TheHVACcontrols(1)arelocatedoverheadandinfront
theoperatorrightabovetheinstrumentpanel.
PTIL17COM1105AA1
HVACON-OffSwitch–Turntheswitch(1)ONtostartthe
HVACsystem.Turntheswitch(1)OfftoturnofftheHVAC
system.
Temperaturecontrolswitch–Turntheswitch(2)clock-
wisetoincreasethecabtemperatureandcounter-clock-
wisetodecreasethecabtemperature.
Blowerspeedcontrolswitch–Operatetheswitch(3)to
controltheblowerspeed.
NOTICE:Iffrontwindshieldfogs-up,switch“ON”theAC
andturntheadjustablefrontACventtothefrontwind-
shield.Operatethewiperforbettervisibility.
NOTICE:Iftherearwindshieldfogsup,impactingthevisi-
bilityofthebackhoe,immediatelystopthemachine.Wipe
therearwindshieldglasswithasuitablecleancloth.Fail-
uretocomplycouldresultinaccidents.
PTIL17COM1106AA2
3-16
