CASE CONSTRUCTION 1107EX - Torque specifications

9-SPECIFICATIONS
Torquespecications
SizeGrade8.8Grade10.9Grade12.9
M5
5.5N·m(4lbft)7.5N·m(5.5lbft)9N·m(6.6lbft)
M6
9N·m(6.6lbft)12.5N·m(9.2lbft)15N·m(11lbft)
M8
22.5N·m(16.5lbft)31.5N·m(23lbft)36N·m(26.5lbft)
M10
44N·m(32lbft)62N·m(45lbft)75N·m(55lbft)
M12
77.5N·m(57lbft)110N·m(81lbft)130N·m(95lbft)
M14
120N·m(88lbft)170N·m(125lbft)210N·m(155lbft)
M16
190N·m(140lbft)265N·m(195lbft)320N·m(236lbft)
M18
260N·m(192lbft)365N·m(269lbft)435N·m(320lbft)
M20
370N·m(273lbft)520N·m(383lbft)620N·m(457lbft)
M22
500N·m(369lbft)700N·m(516lbft)840N·m(619lbft)
M24
640N·m(471lbft)900N·m(665lbft)1080N·m(796lbft)
M27
950N·m(702lbft)1350N·m(996lbft)1620N·m(1195lbft)
M30
1300N·m(955lbft)1800N·m(1328lbft)2160N·m(1593lbft)
Unions,connectionsandplugs
Diameter*
Pitch
M10X1
20.0N·m(14.8lbft)
M12X1.5
35N·m(26lbft)
M14X1.5
45N·m(33.2lbft)
M16X1.5
60N·m(44lbft)
M18X1.5
70N·m(52lbft)
M22X1.5
100N·m(74lbft)
M27X2
200N·m(148lbft)
M33X2
280N·m(207lbft)
M42X2
380N·m(280lbft)
Nutsforpipesandhoses
Diameter*
Pitch
M16X1.5
20N·m(14.8lbft)
M18X1.5
35N·m(26lbft)
M20X1.5
45N·m(33.2lbft)
M24X1.5
60N·m(44lbft)
Flanges
Diameter*
Pitch
M18X1.5
28N·m(21lbft)
M10X1.5
55N·m(41lbft)
M12X1.75
90N·m(66lbft)
M14X2
145N·m(107lbft)
M16X2
230N·m(170lbft)
9-14
