CASE CONSTRUCTION 1107EX - Main components of the machine

1-GENERALINFORMATION
Maincomponentsofthemachine
Withcanopy
PTIL17TLB0050FB1
1.
Engine
13.Frontdrum
2.
Travelpump
14.Tires
3.
Vibrationpump
15.
Excitershaft
4.
TurboCharger
16.
Articulationjoint
5.
Auxiliarymotor
17.
Scrapper
6.Vibrationmotor18.
Operator’splatform
7.
Steeringunit
19.
Elasticsuspension
8.
Steeringcylinders
20.
Battery
9.Fueltank21.
Hydraulicoillter
10.
Hydraulicoiltank
22.
Airlter
11.
Frontrollerframe
23.
Operator’sseat
12.Rearchassis24.
Steeringpump
1-9
