1-GENERALINFORMATION
Rearaxle
Rigidrearaxle.
PTIL14COM0100AA19
Articulationjoint
Thefrontrollingpartandtherearrollingpartarecoupled
bymeansofacouplingcalledarticulationjoint.
PTIL14COM0092AA20
Scrapper
Toremovethesoilandotherparticlesfromthesurfaceof
thedrum,ascrapperismountednearthedrum.
PTIL14COM0093AA21
Operator’splatform(withcanopy)
Theoperator’splatformmountedontherearframesup-
portstheoperator’sseat,controlpanel,steeringsounds
andenginecontrols.
PTIL16TLB0379AB22
1-15
