CASE CONSTRUCTION 1107EX - Forward-reverse lever (FNR) (With ROPS); Emergency stop switch

3-CONTROLSANDINSTRUMENTS
Forward-reverselever(FNR)(WithROPS)
Itallowsthemovementofthemachineinselecteddirec-
tiondrive.
In“N”positionthetranslationcontrolleverisinneutral,
thispositionissignaledfromgreenwarninglight.
Movingtheleverforward,graduallythespeedincreases
forward,untilitreachesmaximumspeedin“F”endstroke
position.
Travelcontrollevershouldbeshiftedtowardstheoperator
beforemovingtoforwardorreverse.
Similarlymovingtheleverbackwards,graduallyreverse
speedincreasesreachingmaximumin“R”endofstroke
position.
1.VibrationmodeON/OFFswitch
2.ForwardReverselever(FNR)
3.Emergencystopswitch
Vibrationamplitudeandfrequencyselector
switch
Compactorsmodelsisequippedwithdoubleamplitude
vibration,formaximumoperatingsupplenessandbest
workingresultconsideringusingmaterials,yieldsandx-
ingworkingtime.
Infact,bythreepositionswitch,it’spossibletodiversify
vibrationamplitude:
•
Highfrequency,lowamplitude(whenpressedontop)
•
Lowfrequency,highamplitude(whenpressedatthe
bottom)
•
Disengagevibration
PTIL17COM1102AB5
PTIL15COM2145AA6
Emergencystopswitch
PushthisswitchtoturnOFFtheengineinanyemergency
case.ThiswillcutofffuelsupplytotheFIP .Thisswitch
willbehelpfulinpanicsituation.Pleasereleasetheswitch
byturningitclockwisebeforestartingtheengineagain.
PTIL15COM2154AA7
3-7
