CASE CONSTRUCTION 1107EX - Page 76

5-TRANSPORTOPERATIONS
PTIL17COM1140GA2
Withcab
DimensionL1L2L3R1R2R3W1
m(in)
5.508m
(216.850in)
3.003m
(118.228in)
1.562m
(61.496in)
0.718m
(28.268in)
0.750m
(29.528in)
0.690m
(27.165in)
2.324m
(91.496in)
DimensionW2W3H1H2H3
m(in)
2.150m
(84.646in)
0.087m
(3.425in)
3.341m
(131.535in)
2.561m
(100.827in)
0.382m
(15.039in)
A1=35°andA2=36°
NOTE:Therollerdrumshellthicknessofferedasstandardofferingis32mm.Forregionswherehighcurbclimbing
abilityiswarrantedanoptionaldrumof25mmthicknessisprovidedtonegotiatethisspecicapplication.Theouter
diameterissameforboth,butthevibrationamplitudechanges.ForVibrationamplitudes,see
5-2
