6-MAINTENANCE

Swingbearing

Greasetheswingbearingevery250h.

Lubricant:CASEAKCELA251HEPMULTI-PURPOSEGREASE

Swingbearing:twogreasettings

Usingagreasegun,injectgreaseofthespeciedtype

inthegreasepointsshowningure.

SMIL16MEX0940AA1

1.Boomswingcylinder

B.Swingbearing

C.Swinggear&pinion

SMIL16MEX1449AB2

6-34
