6-MAINTENANCE

Fueltankstrainer

Cleanthefueltankstrainerperiodically

1.Removethefuelcap.

2.Removethefueltankstrainerlocatedinsidethefuel

llerneck.

3.Inspectthefueltankstrainerfordamage.Ifdamaged,

discardandreplace.Ifingoodcondition,cleanitinan

environmentallysafemanner.

NOTE:dieselfuelisapreferredcleaningagent.Fuelmust

notbeaddedtothetankunlessthestrainerisinplaceand

ingoodworkingcondition.

SMIL16MEX1451AA1

6-57
