3-CONTROLSANDINSTRUMENTS

Fueltank

WARNING

Firehazard!

Whenhandlingdieselfuel,observethefollowingprecautions:

1.Donotsmoke.

2.Neverllthetankwhentheengineisrunning.

3.Wipeupspilledfuelimmediately.

Failuretocomplycouldresultindeathorseriousinjury.

W0099A

Usethestarterkeytounlockthedoor(1)locatedinthe

upperpartofthesidehood.

SMIL16MEX1435AA1

Openthedoortoaccesstothellingcap(2)ofthefuel

tank.

SMIL16MEX1471BA2

3-47
