4-OPERATINGINSTRUCTIONS
Hydrauliccontrolleveroperatingpattern
WARNING
Unexpectedmachinemovement!
Pilotcontrolshavetwodifferentbackhoecontrolspatterns;beforeoperatingthemachine,check
whichcontrolfunctionisactive.
Failuretocomplycouldresultindeathorseriousinjury.
W0185A
NOTICE:wheneverachangeismadetothemachine
controlpattern,alsoreplacethepatternlabelinthecab
tomatchthenewpattern.
SMIL16MEX3175AA1
Usethestarterkeytoopenthepanellocatedintheleft-
handsideofthecab.
SMIL16MEX1536AA2
SMIL16MEX1128AA3
4-13
