CASE CONSTRUCTION CX37C - When necessary; Bulb replacement

228 pages

Save Page as PDF

To Next Page

To Previous Page

6-MAINTENANCE

Whennecessary

Bulbreplacement

Lightingintheoperatorcompartment

1.Useaatscrewdrivertoremovetheprotectiveglassof

theceilinglightinordertoaccessthebulb(1).

SMIL16MEX1117AA1

2.Removethebulbandinstallanewoneofthesame

wattageintheceilinglight.

3.Puttheprotectiveglassontheceilinglightandpushit

tolock.

SMIL16MEX0934AA2
