CASE CONSTRUCTION CX37C - ACCESSORIES; Direct fit buckets

9-ACCESSORIES
9-ACCESSORIES###_10_###
Directtbuckets
Theminimumliftvaluesasfunctionofthearmlengthareshownbelow.Thedataarereferredforworkingoperation
withthedozerbladeupand300mm(11.81in)shoerubber.
Forcabversionwith410kg(903.9lb)counterweight:
•
1.30m(51.18in)arm,minimumliftvalue:370kg(815.71lb).
•
1.60m(62.99in)arm,minimumliftvalue:340kg(749.57lb).
Forcanopyversionwith410kg(903.9lb)counterweight:
•
1.30m(51.18in)arm,minimumliftvalue:350kg(771.62lb).
•
1.60m(62.99in)arm,minimumliftvalue:320kg(705.48lb).
Forcabversionwith560kg(1235lb)counterweight:
•
1.30m(51.18in)arm,minimumliftvalue:420kg(926lb).
•
1.60m(62.99in)arm,minimumliftvalue:380kg(838lb).
Forcanopyversionwith560kg(1235lb)counterweight:
•
1.30m(51.18in)arm,minimumliftvalue:400kg(882lb).
•
1.60m(62.99in)arm,minimumliftvalue:360kg(794lb).
Directtbucketsapplicationasfunctionofthearm(forcabversion)
Generalpurposebuckets
Arm
Capacity
ISO7451(Heaped)
WidthMass
1.30m
(51.18in)
1.60m
(62.99in)
0.06m³(0.08yd³)305mm(12.01in)73kg(160.94lb)
●
●
0.09m³(0.12yd³)457mm(17.99in)93kg(205.03lb)
●
●
0.12m³(0.16yd³)610mm(24.02in)112kg(246.92lb)
●
●
0.19m³(0.25yd³)914mm(35.98in)150kg(330.69lb)x(*)x(*)
Directtbucketsapplicationasfunctionofthearm(forcanopyversion)
Generalpurposebuckets
Arm
Capacity
ISO7451(Heaped)
WidthMass
1.30m
(51.18in)
1.60m
(62.99in)
0.06m³(0.08yd³)305mm(12.01in)73kg(160.94lb)
●
●
0.09m³(0.12yd³)457mm(17.99in)93kg(205.03lb)
●
●
0.12m³(0.16yd³)610mm(24.02in)112kg(246.92lb)
●
●
0.19m³(0.25yd³)914mm(35.98in)150kg(330.69lb)x(*)
x
●Densityofmaterialupto1.6t/m
3
xNotapplicable
(*)TOUSETHISBUCKET(withdensityofmaterialupto1.2t/m
3
)ISMANDATORYTOINSTALLADDITIONAL
COUNTERWEIGHT .
NOTICE:makeparticularattentionwhenswingtheboomtotheleft-handside:theattachmentmaycollidewiththe
cab/canopy.
9-1
