CASE CONSTRUCTION CX37C - Rear view mirrors

3-CONTROLSANDINSTRUMENTS
Rearviewmirrors
WARNING
Avoidinjuryand/ormachinedamage!
Keepthemirrorscleanandproperlyadjusted.
Failuretocomplycouldresultindeathorseriousinjury.
W1078A
Left-handsidemirror
Positionthemirror(A)onthebracket(B)asshowninthe
gureaside.
Horizontallyadjustthemirrorlocationinordertomaximize
visibility.Themirrorinclinationdependsontheheightboth
oftheseatandtheoperator.
SMIL16MEX1510BB1
Verticallyadjustthemirrorlocationsothattheleft-rearend
ofthemachinemaybevisiblefromtheoperator'sseat.
Operateboththemirror(A)andthebolt(C).
SMIL16MEX1508AB2
3-44
