CASE CONSTRUCTION CX37C - Working range

8-SPECIFICATIONS
Workingrange
SMIL16MEX1491FA3
(A)Maximumdiggingreach5315mm(209.3in)
(A’)Maximumdiggingreachonground5200mm(204.7in)
(B)Maximumdiggingdepth3135mm(123.4in)
(B’)Maximumdiggingdepth(8ftlevel)2670mm(105.1in)
(C)Maximumverticalwalldiggingdepth2190mm(86.2in)
(D)Maximumdiggingheight4810mm(189.4in)
(E)Maximumdumpingheight3425mm(134.8in)
(F)Minimumswingradius2350mm(92.5in)
Boomswingradius(left-hand/right-hand)
75°/50°
SAE
27.4kN(6159.8lb)
Bucketdiggingforce
ISO
30.7kN(6901.6lb)
SAE
18.9kN(4248.9lb)
Armcrowdforce
ISO
19.5kN(4383.8lb)
Boomlength:2.5m(98.425in)
Armlength:1.3m(51.181in)
Withboomswingpost
8-6
