Calibration
Calibration
Setup Insight
®
Box
These steps must be performed the rst time the Insight box is powered up and each time it is
reset. They do not need to be redone each time the Insight box is calibrated. Read the Insight
Overview section for basic information about how to use the Insight box.
1. Connect all wiring to Insight box and combine as described in previous section.
2. Start Combine.
3. On the Insight box.
• Choose “Case IH”
• Choose the Combine Model
• Choose the Header type
• Choose the number of height sensors
Calibrate Insight
When you initialize Insight, you will be led directly to this calibration routine. If you wish to
recalibrate at any time - select “>>Perform Calibration” on the Insight main menu.
Standard Calibration
1. Park the combine on a smooth, level surface - preferably a cement driveway or shop oor.
2. Follow on-screen instructions.
• “Raise Header” all the way so that NO sensors touch the ground and press enter
• “Fully Lower Header” all the way down on the skids and press
enter
• Go to Combine Ground Calibration section of this manual
If an error appears on the Insight box - see the Diagnostic section of this manual.
