Overview
Overview
Insight
®
Navigation
How to Navigate
When in a menu (selection arrow appears to left side)
•
Enter: chooses the selected menu choice
• Esc: backs up one menu level
• Up: moves up within the menu choices displayed
• Down: moves down within the menu choices displayed
When in a screen which allows setting of parameters
•
Enter: saves value and exits to menu
• Esc: backs up to last menu level without saving
• Up: increases the value
• Down: decreases the value
Meaning of Status Light
Solid Green:
• System is operating
• No errors detected
Solid Red:
• System is NOT operating
• No height or tilt signals are sent to combine
• You have changed settings which require calibration of Insight, are currently in a menu which will
force a calibration if you make any changes, or are in calibration mode
Solid Green with Flashing red:
• System is operating
• An error has been detected
• Repair problem then clear errors
Flashing Red:
• System is operating
• A sensor has been ignored
• See note in Troubleshooting by Error - ER16
• Repair system - Recalibrate Insight
Screen Contrast Adjustment
To change contrast:
• Press and hold Esc + Up or Down to increase or decrease contrast
Resetting Insight
®
to Defaults
To reset all settings hold + for 5 seconds
