Case IH 9250 - Feathersight Calibration; Combine Ground Calibration

10
Calibration
Feathersight
®
Calibration (if equipped)
Feathersight™ is an optional module to improve the performance of grain systems. It uses
both height sensors and the feeder house pressure sensor to allow seamless control from off
ground to on ground harvesting.
• Insight automatically enables the pressure sensor when detected during calibration.
• If no pressure sensor was detected during calibration, Feathersight is not calibrated or enabled
• Pressure sensing may be manually enabled or disabled by selecting >>Setup>>Optional
Modules>>Feathersight>>Feathersight Enable
1. Park the combine on a smooth, level surface - preferably a cement driveway or shop oor.
2. Follow on-screen instructions.
• “Raise Header” all the way so that NO sensors touch the ground and press enter
• “Lower Head to 4in. “until the skids are 4” off the ground and press enter
• “Fully Lower Header” all the way down on the skids and press
enter
• Go to Combine Ground Calibration section of this manual
If an error appears on the Insight box - see the Diagnostic section of this manual.
Combine Ground Calibration
A full combine calibration must be completed on new installations or if a component of the
header control system is changed on the combine. See combine operators manual for details.
Before completing combine ground calibration, identify if combine has Generation 1 or
Generation 2 Software.
Generation 2 Soware Generation 1 Soware
• All x130, x140, x230, x240, x250
• x010 and x120 with updated software
Version 27 or newer and congured for
Generation 2
• x088, x010 and x120 with software version
26 and older
• All black top x010
1. To view combine software version Go to >>Back>>Diagnostics>>Version, in the combine display.
2. To verify its congured to Generation 2 Go to >>Back>>Toolbox>>Hydraulic.
