Case IH 9250 - Ground Calibration with Generation 2 Software; Ground Calibration with Generation 1 Software

11
Calibration
Ground Calibration with Generation 2 Software
1. Start Combine.
2. Stop forward motion of machine.
3. Disengage header clutch.
4. Go to >>Back>>Calibrations>>Feeder or Header.
5. Follow on-screen commands to calibrate header.
Ground Calibration with Generation 1 Software
1. Start Combine.
2. Stop forward motion of machine.
3. Disengage header clutch.
4. Lower header to ground and hold down button for 2 seconds after header contacts ground.
5. Raise header all the way without releasing the raise button.
If calibration is done correctly, the header will pause momentarily before reaching the top.
Continue to hold the raise button until reaching the top of the stroke.
6. If the header does not pause or if a header sensor error is displayed on the combine screen:
For Insight systems
• Address any error codes on the Insight box in >>Diagnostics>>Error Codes
• Recalibrate Insight
• Retry combine calibration
For Harness Only systems
• Use combine monitor to diagnose sensor voltage errors
