Diagnostics
Symptom Problem Solution
Height works but not Tilt Verify combine display had
header icon with wavy line under
header not straight line (Flagship
combines only)
Verify wiring is connected as
follows
Combine software problem
See Operation manual section
Read sensor input values to
combine at sensor diagnostics
area of combine screen
Pin 1 of Y311 header connector
to Pin 10 of Y101 on the Insight
box to “Left” on the combine
screen
Pin 2 of Y311 to Pin 12 of Y101
to “Right”
Pin 3 and Pin 4 of Y311 to Pin
11 of Y101 to “Left Center” and
“Right Center”
Have a CIH technician update
the combine header control
software.
Header is not level with header
control engaged.
If the header tilts completely to
one side:
If the header runs slightly out of
level but functions correctly:
Wiring connected improperly Verify that the individual sensor
wiring is connected to the main
wiring harness at the rear of the
header properly.
See Installation section for
details.
This symptom will occur if the
Left and Right sensor wiring are
in the incorrect position.
Perform Insight Cal and combine
Quick-Cal or Header Cal.
