32
Diagnostics
Error Code Problem Solution
ER32
Center sensor signal greater
than 4.7V
Wiring problem
Sensor failure
Ground wire to sensor is open
Signal short to power
Calibrate Insight Box
Calibrate Headsight Box
Calibrate Combine
See sensor test instructions
ER33
Center sensor swing less than
0.6V
Center sensor mechanical range
is restricted
Sensor failure
Verify sensor is not obstructed in
swing
Verify sensor can collapse fully
with header lowered
Adjust down stop to allow greater
range
See sensor test instructions
ER36
Center sensor expected but not
detected
Center sensor not properly
connected
Not enough swing during cal
Incorrect number of sensors
selected in setup
Sensor failure
Control box /wiring failure
Verify harness is connected to
sensor 1
Verify harness is connected
properly to control box harness
Verify that signal wire (Pin B
white wire of sensor cable) is
connected to PIN8 of connector
Y101 (Insight box)
Make sure sensor meets
requirements in - Advanced
Information - Basic Requirements
section of this manual
Go to >>Initial Setup>>Number
Sensors and choose the correct
number of sensors
See sensor troubleshooting
instructions
Contact Headsight
ER37
Center sensor detected but not
expected
Incorrect number of sensors
selected in setup
Harness wiring error
Control box /wiring failure
Go to >>Setup>>System Select
and choose the correct number
of sensors
Verify that no wires contact PIN8
of connector Y101
Contact Headsight
