Case IH VISION PRO - AFS Pro 1200 Display: Screen Details; Run Screen Content Breakdown

11
RUN SCREEN 1
RUN SCREEN 5
RUN SCREEN 3
RUN SCREEN 7
RUN SCREEN 2
RUN SCREEN 6
RUN SCREEN 4
Left-Hand Area Run Screen
Engine Power Eng Speed System Speed
Slip %
CERPM –1 x 2 EHR – 1 x 2
MFH
Levers Work Lights Levers
Cross Track Area counter Trip Fuel Used (Counter)
Fuel Rate (gal/ac) HVAC Steering Rate
Left-Hand Area Run Screen
Engine Power
Map – 2 x 6
Slip %
MFH
Levers
Cross Track
Fuel Rate (gal/ac)
Left-Hand Area Run Screen
Engine Power
Camera – 2 x 6
Slip %
MFH
Levers
Cross Track
Fuel Rate (gal/ac)
Left-Hand Area Run Screen
Engine Power
UT/VT – Phase 2
(NA in Phase 1)
Slip %
MFH
Levers
Cross Track
Fuel Rate (gal/ac)
Left-Hand Area Run Screen
Engine Power Eng Hrs
EHR – 1 x 2
Slip % Avg Work rate
MFH Total Fuel Used Remote Status
Levers Fuel used eld
Cross Track Fuel used area eld average Camera – 1 x 3
Fuel Rate (gal/ac) Time in work
Left-Hand Area Run Screen
Engine Power
Map – 1 x 6
Coverage Logging
Slip % Cross Track error
MFH Remark
Levers Nudge
Cross Track On-Line Agress
Fuel Rate (gal/ac) Swath Acq
Left-Hand Area Run Screen
Engine Power Ride Control Field Distance
Slip % Road Distance
MFH Area Remaining
Levers Hitch Position – 1 x 5 Area counter
Cross Track Coverage Area
Fuel Rate (gal/ac) Current Fld Area
Introduction to the AFS Pro 1200
™
Display
