19
CVXDrive
™
REF NAME FUNCTION
14
Constant RPM
(CRPM)
Set point 1
Enables engine RPM set point 1.
Press and hold to store current
engine RPM as set point 1.
15
Constant RPM
(CRPM)
Set point 2
Enable engine RPM set point 2.
Press and hold to store current
engine RPM as set point 2.
16
Transmission
Aggressiveness
Cycles through gear transition rate (CVXDrive):
Low – slow gear up to match target speed.
Medium – medium gear up to match
target speed.
High – Fast gear up to match target speed.
17 Not Used
This button is currently not assigned to a
function.
18 Not Used
This button is currently not assigned to a
function.
19
Left RPM
Control
The left-hand throttle is the primary engine
throttle and functions like any other tractor
throttle: it controls engine speed from idle
to the rated engine speed. Move the lever
forward to increase engine speed, move the
lever rearward to decrease engine speed.
20
Right RPM
Control
Use the right-hand throttle to select the
maximum engine RPM when the engine is
fully loaded. In most circumstances select
the maximum permitted growth point in
engine RPM, or select the maximum drop
point in engine RPM.
In automatic mode, the throttles work
together to set engine speed parameters
for various applications.
18
16
17
15
14
20
19
