If a congurable button is not set to a function, pressing the button will prompt the conguration screen in the display.
REF NAME FUNCTION
11
Hitch Express Raise
Raises hitch to upper limit. Holding the “2nd Function” button on the back of the
MultiFunction handle while pressing this button will command the front hitch to
express raise. Pressing again while linkage is raising will pause the lift.
12
Hitch Express Lower
Lowers hitch to working depth. Press and hold this button lowers to the lower limit
until released. Holding the 2nd function button on the back of the MultiFunction
handle while pressing this button will command the front hitch to express lower.
13
1st Remote valve extend
Extend ow as long as the button is pressed or starts the timer
if the button is pressed and released, and the timer function is set up and “ON”.
14
1st Remote valve retract
Retract ow as long as the button is pressed or starts the timer
if the button is pressed and released, and the time function is set up and “ON”.
15
2nd Remote valve extend
Extend ow as long as the button is pressed or starts the timer
if the button is pressed and released, and the timer function is set up and “ON”.
16
2nd Remote valve retract
Retract ow as long as the button is pressed or starts the timer
if the button is pressed and released, and the time function is set up and “ON”.
17
Thumb wheel
Power Drive: Adjust the Automatic Productivity Management (APM) Field
maximum speed set point when APM “Field” is activated. Adjusts the APM
Transport mode lowest gear when APM “Transport” is activated.
CVXDrive: Changes the maximum speed of the current Target Speed (target speeds
F1, F2, F3 or R1, R2, R3).
18
Second Function
Enables secondary function of some buttons. Enables calibration if pressed for
2 seconds within 20 seconds after Key-on/crank.
19
Headland Engage /
Step Switch
Power Drive / CVXDrive: Press this button will engage the Headland Management
Control (HMC) function which will activate the recorded sequence. The record
and play functions can also be activated on the throttle panel. See page 49 more
details and explanation.
20
Neutral
The Neutral button on the left hand shuttle will place the transmission in a neutral
position for stopping and parking. The left-hand shuttle is also the forward and
reverse placement of the tractor to move and is the tractors park brake.
* Function is limited by system conditions, see system notes for this function.
