REF NAME FUNCTION
1
Remotely Controlled
Mirrors
Slider with the mirror adjustment button: Select Left (L) or Right (R) mirror adjustment
for the outside mirrors (if equipped).
Right/left and up/down adjustment allows the operator to move the mirrors from the
tractor seat to view the area behind the tractor.
2 Extend/Retract control
Slider with the mirror adjustment button: Selects Left (L) or Right (R) mirror.
Extends or retracts selected mirror.
3 Mirror Defrost (optional)
Push the top of the button to turn the defroster on to clear the mirrors of frost or
condensation. Push the bottom of the button to turn off.
4
Guidance (Electronic
Steering) enable control
Push the top of the switch to turn guidance Field Mode on. Return switch to center to
turn Guidance and the system off. This is called Road Mode and is used when the tractor
leaves the eld and guidance is no longer needed or the machine is being transported.
5 Transport lock
3 point rocker switch:
Top Position: EHR remote valves and hitch is unlocked and will function.
Middle Position: EHR remote valves unlocked and functional, hitch is locked
and will not function.
Bottom Position: EHR remote valves and hitch are locked and will not function.
6 Fan Speed Control Controls the fan speed for the HVAC system. Turning it clockwise increases fan speed.
7 Max Defrost
Diverts all of the fan air to the defrost vents for quick clearing of the windows
of frost or condensation.
8 AC Power Turns the Air Conditioning system on and off.
9 AC Auto Mode
Switches air ow control to the auto mode so the fan will run at the necessary speed to
achieve the temperature in the cab set by the operator.
10 Window Vents Switches the air ow to the front vents to blow directly on the operator.
11 Front Vents Switches air ow to the upper vents in the cab.
12 Upper Vents
Switches the air ow to the window vents to clear up condensation on the inside
of the windows.
13 HVAC Temperature Control
Controls the inside temperature of the cab. Turning it clockwise increases cab
temperature, counterclockwise decreases cab temperature.
14 Auto Control Enables assignment request from an attached implement via the ISOBUS.
15 ISOBUS Shortcut Disables assignment request from an attached implement via the ISOBUS.
16 Work Lamp Master Switch Switches worklights off.
17a Memory 1
This toggle switch will allow the operator to toggle between the pre set light congurations
set up in the AFS Pro 1200. The setup of the lights is done through the light wizard. If
the lights are not pre set by the operator, all of the lights will come on when the lights are
turned on with the light stalk. The head lights must be turned on with the light control
stalk located on the left side of the steering column.
17b Memory 2
18 Hazard Lights (Latch) Switches ashers or hazard lights ON.
19 Beacon Light If equipped, this switch turns on the beacon light(s).
