CASE IH PRO VISION OPERATING SYSTEM GUIDE
62
AFS Connect Magnum
™
Tractor Cab Features (continued)
On the side of the operator seat there is a USB port (A) handy to
connect iPads sitting in the RAM holder next to the AFS Pro 1200
display. Next to the USB port are the levers to adjust the armrest (B)
to meet the requirements of the operator.
The Foot Throttle (1) can be used as the throttle in a
PowerDrive or CVXDrive
™
congured tractor in place of the
MultiFunction handle. This is very handy especially in a
loader application providing the operator with better control
of the tractor.
Harley bars (2) provide foot comfort during operation.
The foot-activated Engine Brake can be used when
pulling heavy loads with the tractor allowing the operator
to have better control of the load and handle it safely.
Additional
connection ports
are located behind
the operator seat.
1
2
A
B
