5-TRANSPORTOPERATIONS

CX130Cwithblade

SelecttheHworkmode.

Alignthemachinetothetrailer,soasthebladefacesthe

trailerramps.Fullyraisetheblade.

NOTICE:Startingfromthisposition,thetravelcontrol

leversmustbepushedforwardtomoveontherampsand

onthetrailerbed.Conrmthetravelcontroldirections

beforestartmovingontotheramps.

Getclosetotherampsandoperatethearmandbucket

controlssothatthearmisslightlyextendedandthebot-

tomsideofthebucketisabout20cm(7.9in)abovethe

trailerbed.

SMIL20CEX0023AA6

Slowlyclimbthetrailerrampskeepingthebucketcloseto

thetrailerbed.Slowlytravelonthetrailerbedtoreach

therestingposition,givingparticularattentiontotheat-

tachmentsoasnottotouchthetrailerbed.

SMIL20CEX0026AA7

Afterreachingtherestingposition,lowerthebladeonthe

supportingblock.

Makesurethatthereisenoughspacebetweentheblock

andthetrackstoroutethetie-downchains.

SMIL19CEX2664AA8

Slowlyturntheupperstructure180°.

SMIL20CEX0027AB9
